Air Balance - SAF-L Type
It generates
less noise since it uses only compressed air without any
electric power.
Suitable for
repetitive short-distance transport.
Able to adjust
speed to your movements and applicable to three-dimensional
parabolic operations.
Outstanding
precision without any shaking or cushion.
Its circuit is
simple but enough for all necessary functions. It is not
easily broken and it is also easy to find components.
You can speed up
or slow down the work with your hand’s movements.
Since it is
always balanced, it does not move in any direction when
stopped.
You can reduce
the transport time of steel plates with our 4×8/5×10
four-column loading stations.
| Model | Support Type | Jig Type | Stroke | Allowable weight |
|---|---|---|---|---|
| SAFG-VL200 | Jib | Suction | 1000/1300 | 200 |
| SAFG-VL400 | Jib | Suction | 1000/1300 | 400 |
| SAFR-VL200 | Rail | Suction | 1000/1300 | 200 |
| SAFR-VL400 | Rail | Suction | 1000/1300 | 400 |
| SAFR-V200 | Rail | Suction | 1000/1300 | 200 |
| SAFR-V400 | Rail | Suction | 1000/1300 | 400 |
| SAFR-C200 | Rail | Clamp | 1000/1300 | 200 |
| SAFR-C400 | Rail | Clamp | 1000/1300 | 400 |
| SAFG-C200 | Jib | Clamp | 1000/1300 | 200 |
| SAFG-C400 | Jib | Clamp | 1000/1300 | 400 |
| SAFR-P200 | Rail | Permanent magnet | 1000/1300 | 200 |
| SAFR-P400 | Rail | Permanent magnet | 1000/1300 | 400 |
| SAFG-P200 | Jib | Permanent magnet | 1000/1300 | 200 |
| SAFG-P400 | Jib | Permanent magnet | 1000/1300 | 400 |
